MILITÄRA NYHETER
Nyheter från Crane Interpoint!
Lanseras under 2020
New DC/DC from Crane Interpoint:
• Surface Mount Package - MGH
• Operating Temperature -55°C to +125°C
• 16 to 50 Volt Input
• Transient Protection 80 Volts for up to 120 ms
• 70 Volts for 15 Volt Single and Dual Models
• Fully Isolated, Magnetic Feedback
• Fixed Frequency Switching
• Inhibit Function
• Short Circuit Protection
• Under Voltage Lockout
• Up to 79% Efficiency, Typical
Läs Mer
New DC/DC from Crane Interpoint:
• Small Footprint, 0.79 in2 (5.1 cm2) - MCH
• Operating Temperature -55°C to +125°C
• 16 to 50 Volt Input
• Transient Protection 80 Volts for up to 120 ms
• 70 Volts for 15 Volt Single and Dual Models
• Fully Isolated, Magnetic Feedback
• Fixed Frequency Switching
• Inhibit Function
• Short Circuit Protection
• Under Voltage Lockout
• Up to 79% Efficiency, Typical
Läs Mer
• Radiation Tolerant (up to 100 krad) Space DC/DC Converter
• Operating Temperature -55° to +125°C
• Qualified to MIL-PRF-38534 Class H and K
• Input Voltage Range 16 to 40 volts
• Transient Protection 50 volts for 50 ms
• Fully Isolated, Magnetic Feedback
• Fixed High Frequency Switching, 600 kHz Typical
• Trim Function or Remote Sense on Single Output Models
• Inhibit and Synchronization Functions
• Indefinite Short Circuit Protection
• Typical Efficiency up to 83%
Crane Interpoint är en ledande tillverkare av DC/DC för Militär, Avionics och Aerospace applikationer. Crane Co grundades 1855 i USA och har sedan dess blivit en av de största globala aktörerna inom sin nisch.
Kontakta oss med ert nästa projekt så hjälper vi er.
NYHET! Kommande produkt. Lanseras under 2019.
Crane Interpoint lanserar en ny DC/DC:
-
Wide Input, 8 - 50Vdc
-
Upp till 30W
-
High Reliability
-
Verkningsgrad på minst 90%
-
Temperature -55ËšC till +105ËšC
-
MIL Std
